AV over Twisted-Pair

Game-changing HDBaseT and SDVoE ease your AV deployments…

May 1st, 2019
Content Dam Cim Native Articles 2019 05 Avoverip Thumbnail

While the term video over Internet Protocol (IP) has existed for quite some time, it essentially has been used to refer to any type of Internet-based video transmission. However, regardless of the cabling medium, most of these systems to date have been supported by traditional audiovisual (AV) architectures where signals are sent and received via AV transmitters, receivers and video matrix switches rather than using true Ethernet LAN switches. This has prohibited AV transmission from truly converging onto existing network cabling infrastructures, and they have instead remained on their own standalone network. But all that is changing with AV over IP that uses standard network equipment to transmit and switch AV signals.

HDBaseT: The 5Play Game Changer

Over the past decade, balanced twisted-pair copper cabling (i.e., Category 6 and Category 6A) has become an AV-supporting medium using baluns that enable composite and analog video to extend over the twisted-pair cabling. The use of AV over twisted-pair cabling really came to fruition in 2010 with the introduction of the HDBaseT standard.

Since it was introduced by the HDBaseT Alliance, HDBaseT has evolved to support what has been dubbed “5Play”—the transmission of ultra-high definition 4K video and audio along with 100 Mb/s Ethernet (100Base-T), USB, bidirectional control signals and 100W of power (power over HDBaseT) over a single twisted-pair cable to 100 meters using standard 8P8C (RJ45) connectivity.

While HDBaseT can run over Category 5e (to limited distances) and Category 6 cabling, the HDBaseT Alliance and HDBaseT equipment vendors all recommend the use of Category 6A twisted-pair unshielded cabling at a minimum to support the bandwidth required for 4K signals and reach the full 100-meter distance. Many AV vendors recommend stepping that up to Category 6A or Category 7A shielded twisted-pair cable to ensure a truly robust performance—especially for installations with unmanaged environmental factors. Shielded Category 6A or Category 7A offers better resistance to alien crosstalk, which has a significant impact on HDBaseT signals wherever multiple cable are bundled together. Further, with power over HDBaseT (POH) running at higher levels of 100 Watts, shielded cabling offers far superior heat dissipation and thermal stability.

While HDBaseT remains the most popular AV protocol over twisted-pair cabling and is at least a step towards using a common cabling medium, it is not true IP as it used a different packetization protocol (T-packets). Further, an HDBaseT system must use HDBaseT equipment, so it essentially must remain as a standalone system and therefore does not meet the true definition of IP convergence.

SDVoE: The Ethernet Solution

Today, there are newer AV protocols that truly can be considered an IP system because they transmit AV signals over standard off-the-shelf Ethernet LAN switches. Introduced in 2017, Software Defined Video over Ethernet (SDVoE) that supports uncompressed 4K video, audio, control and 1 Gb/s Ethernet is one such platform that aims to offer greater saving, flexibility and scalability compared to HDBaseT since it addresses the full 7-layer OSI model and leverages what we in the IT industry already use for transmitting data—standards-based network cabling, Ethernet, TCP/IP and low-latency switching. Plus, it eliminates the use of AV video matrix switches, which typically cost about 90% more per port than a standard Ethernet switch since Ethernet ports are bidirectional and can therefore be used as both an AV input and output port. Ethernet switches also typically take up about a quarter of the rack unit space compared to a video matrix switch, and they support power over Ethernet (PoE) capable of delivering up to 90 Watts of power.

While a few other AV over IP protocols have been introduced, such as the Society of Motion Picture and Television Engineers SMPTE 2110 standard that defines the uncompressed transmission of HD video over IP, JPEG-2000 lightly compressed video over IP, and high-efficiency H.264 and H.265 video compression for video over IP, most industry professionals see SDVoE and the most disruptive technology and the one that truly paves the way for fully converged AV over IP. In response, the HDBaseT Alliance introduced HDBaseT over IP shortly after the introduction of SDVoE to also leverage standards-based network infrastructures and 10 Gb/s Ethernet switches for cross-campus transmission, but it requires HDBaseT-to-HDBaseT-IP bridges and HDBaseT-IP switches.

When it comes to SDVoE, it’s not just that Category 6A cabling is recommended—it’s required. SDVoE requires a 10 Gb/s Ethernet network (10GBASE-T), which can only be supported by a minimum of Category 6A cable. And for the same reasons as HDBaseT, shielded cabling is recommended—eliminating crosstalk and providing superior heat dissipation and thermal stability for remote powering (PoE in the case of SDVoE).

Prepare Your AV Cabling System

Regardless of whether your AV system is HDBaseT or a true IP solution like SDVoE, you need to ensure you have the right cabling system to support it — one with superior performance to fully combat video disrupting alien crosstalk for a clearer picture. In addition, selecting shielded twisted-pair cabling with a higher operating temperature of 75°C will ensure better heat dissipation to support the higher power levels of POH and PoE (100 and 90 Watts) needed to power video displays.

p>

To avoid the use and expense of unsightly outlets and patch cords, digital displays can be connected directly to the cabling infrastructure using field-terminated plugs and a standards-based MTPL configuration. Siemon’s robust high-performance Z-PLUG field-terminated plug can be terminated to both shielded and unshielded cables, including Category 6, Category 6A and Category 7A. Learn more about our cabling solutions to support your AV over twisted-pair application.
