Patch-cable bend radius a tight issue

From a cable-management standpoint, I find that patch cables with stranded conductors have a more relaxed lay than patch cables with solid conductors, which tend to be more rigid

Th 91956

From a cable-management standpoint, I find that patch cables with stranded conductors have a more relaxed lay than patch cables with solid conductors, which tend to be more rigid.

Th 91956
Click here to enlarge image

Last August, the first addendum to the Telecommunications Industry Asso ciation's (TIA-www.tiaonline.org) TIA/EIA-568B.1 Commercial Building Telecommunications Cabling Standard was published. The addendum, entitled "Minimum 4-Pair UTP and 4-Pair ScTP Patch Cable Bend Radius," does not have a great deal of verbiage, but may have a significant impact on cabling-plant managers' ability to manage patching fields within telecommunications rooms.

Dennis Mazaris, RCDD, played a significant role in the ratification of Addendum 1 to TIA/EIA-568B.1, including presenting test data showing that cabling channels do not necessarily suffer performance degradation from tightly bent patch cables. Mazaris is president of PerfectPatch (www.perfectpatch.com), which manufactures a product by the same name-a patch-cable management device.

We interviewed Mazaris to get his perspective on issues surrounding the TIA addendum and patch-cable management:

CI&M:Please tell us what is specified in Addendum 1 to TIA/EIA-568B.1.

Mazaris: The addendum specifies the minimum inside bend radius for both unshielded twisted-pair (UTP) and screened twisted-pair (ScTP) patch cables, under no-load conditions, meaning the cables are not bearing any weight. For UTP patch cables, the minimum inside bend radius is 6 millimeters (mm), which is 0.25 inches. For ScTP patch cables, the minimum inside bend radius is 50 mm, which is 2 inches.

CI&M:Is this addendum an update to any previously existing standard addressing patch cables?

Mazaris: No it is not. Many people believe that a minimum patch-cable bend-radius of 1 inch had been specified previously. But that radius specification applied to cable in terminated spaces only, and did not apply to patch cables.

CI&M:In many cabling systems, patch cables are used in several places-in the work area from a PC to an outlet; in the telecom room between connecting hardware and network equipment; and, of course, between patch panels in systems that implement cross-connections. Do these specifications apply to patch cables used in all those environments?

Mazaris: Yes, the specifications apply to what are commonly called equipment cables and work-area cables, as well as to cables used between patch panels.

CI&M:Are patch cables constructed differently from cables used in the horizontal, such that they can withstand bending better than horizontal cable?

Mazaris: That question raises an interesting point. Most patch cables incorporate stranded copper conductors, whereas horizontal cable incorporates solid conductors. However, TIA/EIA-568B.1 allows for the use of solid conductors in patch cables, so patch cables are available with stranded or solid conductors. The patch-cable bend-radius specifications apply to cables regardless of whether they include solid or stranded conductors. From a cable-management standpoint, I find that patch cables with stranded conductors have a more relaxed lay than patch cables with solid conductors, which tend to be more rigid.

CI&M:The TIA is not far away from having all the T's crossed and I's dotted on the Category 6 standard. Will these patch-cable specifications apply to Category 6 systems?

Mazaris: Yes, Category 6 systems will be subject to the 6-mm minimum inside bend radius for UTP and 50-mm inside bend radius for ScTP specifications.


Dennis Mazaris, RCDD, is president of PerfectPatch (www.perfectpatch.com).
