OPC Foundation joins Ethernet-APL project group

Aug. 14, 2020
The advanced physical layer (APL) for Industrial Ethernet is critically important for OPC's UA field level strategy in the process automation industry, the Foundation says.

OPC Foundation recently announced that it has joined the APL project group in order to support the development and promotion of an advanced physical layer (APL) for Industrial Ethernet -- suitable for use in demanding applications and hazardous locations in the process industry -- named “Ethernet-APL”.

To date, the APL Project Group has consisted of 12 industry partners, and the three leading fieldbus organizations in process automation: FieldComm Group (FCG), ODVA, and Profibus & Profinet International (PI).

In a June 25 press statement, Jörg Hähniche of Endress+Hauser and chairperson of APL project group, commented:

“We welcome the OPC Foundation. While the APL project is well advanced, we are even more pleased that OPC Foundation has joined the project. Their membership completes the cooperation, as all leading organizations are now working on one Ethernet Advanced Physical Layer solution which will be integrated into their respective specifications. This has an enormous customer benefit, especially since one Ethernet Advanced Physical Layer solution now fits many applications. By jointly cooperating, we hope to benefit from the many years of experience of OPC Foundation thus benefiting a wide range of customers.”

Ethernet-APL describes a physical layer for Ethernet communication technology which is especially developed for the requirements of the process industries. The development of Ethernet-APL was determined by the need for communication at high speeds over long distances; the supply of power and communication signals via common single, twisted-pair (2-wire) cable; and protective measures for the safe use within hazardous areas.

The decision of the OPC Foundation to join the APL project group is closely related to the Foundation's strategy to extend OPC UA to the field level in discrete and continuous manufacturing. For this, the OPC Foundation launched the Field Level Communications (FLC) initiative in November 2018, supported by an impressive list of major automation suppliers.

Peter Lutz, director of the OPC Foundation FLC Initiative, notes: “APL is recognized by the OPC Foundation and particularly its FLC initiative to be a critical important piece in the strategy to expand OPC UA to all use cases and requirements in factory and process automation, supporting the vision of a fully scalable, industrial interoperability solution, from sensor to cloud.”

In order to meet all requirements for use cases from end users, suppliers, and integrators from process automation to factory automation, OPC Foundation notes that its FLC-related technical work includes the following topics:

  • Definition of an “Automation Component” with functions, interfaces and behaviors that are common to the different FLC-conformant devices used in various applications in process and factory automation.
  • Definition of system behaviors and sequences for common functionalities e.g. bootstrapping, connection establishment, etc.
  • Harmonization and standardization of application profiles like IO, motion control, functional safety, system redundancy.
  • Standardization of OPC UA information models for field level devices in online and offline scenarios e.g. device description and diagnostics .
  • Guarantee the best integration of OPC UA companion specifications like FDI, FDT, PA-DIM, ADI (Analyzer Device Integration), Module Type Package (MTP), and MDIS (Oil&Gas), VDMA pumps, UMATI, Spectaris, and so forth.

Stefan Hoppe, president of OPC Foundation, adds: “It is because of the broad acceptance, high flexibility, and vendor independence of OPC UA that various initiatives in the process industry, including NAMUR Open Architecture (NOA), the Open Process Automation Forum (OPAF), Module Type Package (MTP), and MDIS (Oil&Gas), rely heavily on OPC UA as the core technology to model devices from different vendors and exchange information between them. The extension to utilize APL as a transport layer is a logical progression – the combination of OPC UA with Ethernet-APL will be the future standard for many users in the process industry.”

As further outlined by the OPC Foundation's recent statement:

"Because of its versatility and manufacturer independence, OPC UA is already used today in many different industrial applications. However, OPC UA is much more than just a transport protocol in its traditional sense. Instead, OPC UA is an industrial, protocol-agnostic framework for the Industrial Internet of Things and Industry 4.0 that contains mechanisms for secure, reliable, manufacturer and platform-independent information exchange, as well as options for semantic information modeling and self-description of devices. OPC UA scales from the sensor across all levels to MES / ERP and also into the cloud including cyber security mechanisms built from the start."

Users can learn more about Ethernet-APL by visiting the websites of OPC Foundation (OPCF), Profibus & Profinet International (PI), FieldComm Group (FCG), and ODVA, and in a white paper entitled “Ethernet to the Field: Future solution for process automation and instrumentation in remote and hazardous locations,” which is available in PDF format here.

For more information about APL, visit: www.opcfoundation.org/apl.
