Cabling Spaghetti Slide 8

Nov. 28, 2012

Attribution: By Achim Hering (Own work) [GFDL or CC-BY-3.0], via Wikimedia Commons

Point Tupper, Nova Scotia coal power plant, Unit 2, Cable Spreading Room, below the control room.

High-powered cabinets located above this picture and the previous one sit on top of holes in the construction’s concrete slab, located inside the plant’s control room.
