Core infrastructure failures: Must-see photos

As with apples, so it goes with ICT cabling installations. There's a bad one in every bunch...

Matt Vincent
Jul 10th, 2019
Tiny People 700921 960 720
Pixabay

Welcome to our periodic round-up of the most penetrating structured cabling site work failures, as glimpsed on social media at Reddit's photo sub-communities for 'Cablefail' and 'Cablegore.'


Core1Reddit"Yup, that's the core infrastructure of a multi-million dollar SAN." -- Reddit/Cablefail OP [orig. poster]: IDGAFMFROFL


Core2Reddit"I guess it's quicker than grabbing the cable stretcher from the truck...the worst attempt at a BIX I’ve ever seen..." -- Reddit/Cablefail OP [orig. poster]: elhorneto

Core3Reddit"Only 1/4 of the cables are plugged in." -- Reddit/Cablegore OP [orig. poster]: iLiveInABowl

Core4Reddit"When the security guy just DGAF." -- Reddit/Cablegore OP [orig. poster]: ipsonator

Core5Reddit"When you order a fiber-optic cable and open up the box 🤔 " -- Reddit/Cablegore OP [orig. poster]: ResidentTarget

Send your must-see cabling photos to mvincent@endeavorb2b.com.
