Platinum Tools showcases ezEX-RJ45 shielded connectors at 2018 CEDIA Expo

Now shipping, the new connectors feature the company's integrated Hi-Lo stagger load bar and allow “big” conductors to pass through the front end of the connector, making it easy to verify the wiring sequence before terminating.

Aug 23rd, 2018
Platinum Tools showcases ezEX-RJ45 shielded connectors at 2018 CEDIA Expo
Platinum Tools showcases ezEX-RJ45 shielded connectors at 2018 CEDIA Expo

Platinum Tools, a specialist in products for the preparation, installation, hand termination and testing of wire and cable, will feature its recently launched ezEX-RJ45 shielded connectors during CEDIA Expo 2018, held in San Diego from Sept. 6-8 at the San Diego Convention Center, in the company's booth #4352.

Now shipping, the ezEX-RJ45 shielded connectors feature the company's integrated Hi-Lo Stagger Load Bar and allow “big” conductors to pass through the front end of the connector, making it easy to verify the wiring sequence before terminating. The new connectors are typically used with either Category 6 or 6A cabling and are terminated using the Platinum Tools EXO Crimp Frame and EXO-EX Die (100061C) products.

“Our new shielded ezEX-RJ45 connectors are designed for larger cables and conductors,” comments Lee Sachs, Platinum Tools, Inc. president and general manager.

Per Platinum Tools, listed features and specifications for the ezEX-RJ45 product line include:

ezEX™44 Shielded CAT6 Connector, Internal Ground

· Hi-Lo stagger to isolate each conductor

· Simple one piece/pass through design, no bars or liners

· Shielded 5e/6/6A compliant

· Insulation Diameter (Conductor) - Size range: 0.039in. – 0.044in. (1.0 –1.12mm)

· Max Outer Diameter: 0.2805in. (7.1mm)

· Solid or Stranded 24-22 AWG

· TAA, TIA, RoHS, UL & FCC compliant

· Made in the USA

ezEX™44 Shielded, External Ground, CAT6 Connector

· Hi-Lo stagger to isolate each conductor

· Simple one piece/pass through design, no bars or liners

· Shielded 5e/6/6A compliant

· Insulation Diameter (Conductor) - Size range: 0.039in. – 0.044in. (1.0 –1.12mm)

· Max Outer Diameter: 0.305in. (7.75mm)

· Solid or Stranded 24-22 AWG

· TAA, TIA, RoHS, UL & FCC compliant

· Made in the USA

ezEX™48 Shielded, External Ground, CAT6A Connector

· Hi-Lo stagger to isolate each conductor

· Simple one piece/pass through design, no bars or liners

· Shielded 6/6A compliant

· Insulation Diameter (Conductor) - Size range: 0.043in. – 0.048in. (1.09 –1.22mm)

· Max Outer Diameter: 0.305in. (7.75mm)

· Solid or Stranded 23-22 AWG

· TAA, TIA, RoHS, UL & FCC compliant

· ezEX™44 - ezEX-RJ45® CAT6 Connector

· Made in the USA

For pricing and additional information, visit www.platinumtools.com, call (800) 749-5783, or email info@platinumtools.com.
